SUN LOUVERS

Sun louvers are of the most effective methods of sun control and are popularizing rapidly owing to factors such as high durability, energy saving, cost economization and customization in choice.

C & L Products is one of Malaysia’s top companies specialized in the manufacturing sun louvers and metal strip ceilings. The business takes great pride in its experience in the industry, innovative fixing systems and expertise in providing customers with total solution.

The company offers a wide variety of louvers including aluminium sun louvers, box louvers and aerofoil louvers, all of which offer effective sun control, visually pleasing designs and high value for money. Each product is available in vertical and horizontal types, add-ons, different colours, adequate thickness and panel size.

Other products include strip ceiling, metal ceiling, tile ceiling and cell ceiling, all of which are replacing the traditional styled roofs thanks to their many advantages, some of which include added resistance to moisture and harsh environmental conditions, aesthetic value, durability, additional strength to the house’s structure and minimal maintenance.

CNL84/2S SUN LOUVERS

CNL84/3S SUN LOUVERS

CNL84/4S SUN LOUVERS

CNL84/5S SUN LOUVERS

CNL84/6S SUN LOUVERS

CNL84/7S SUN LOUVERS

CNL95Z SUN LOUVERS

CNL140Z SUN LOUVERS

CNL 153S SUN LOUVERS

CNL93S SUN LOUVERS

BOX LOUVERS

CNL 100 X 20 BOX LOUVERS

AEROFOIL LOUVERS

CNL150AF AEROFOIL LOUVERS

GROOVE LINE CEILING

CNL100 / 100G GROOVE LINE CEILING

CNL100 / 100G GROOVE LINE CEILING WOOD GRAIN 950

CNL200G GROOVE LINE CEILING

HAIR LINE CEILING

CNL100S HAIR LINE CEILING

CNL150S HAIR LINE CEILING

SQ CELL CEILING

CNL 200SQ CELL CEILING

SC SCREEN CEILING

CNL 100SC SCREEN CEILING

BAFFLE CEILING

CNL 100 X 20 BAFFLE CEILING

LAY ON TILE CEILING

CNL 606LO-2 LAY ON TILE CEILING

CLIP IN ON TILE CEILING

CNL 606CI-1 CLIP IN ON TILE CEILING

CNL84/2S TYPE LOUVERS

CNL84/2S TYPE LOUVERS

Panel Size

85mm Effective Width

Notes

Panel to Panel Spacing Available

At 74 / 86 / 70 / 100mm

Available in Horiztal& Vertical Type

Thickness

0.35mm ( Alumzinc Panel )

0.50mm (Aluminium Panel

Accessories

Alum 2S – 7S Carrier ( Base on Panel Spacing )

Colour

Prepainter wood garin 870 / 95

CNL84/3S TYPE LOUVERS

CNL84/3S TYPE LOUVERS

Panel Size

85mm Effective Width

Notes

Panel to Panel Spacing Available

At 74 / 86 / 70 / 100mm

Available in Horiztal& Vertical Type

Thickness

0.35mm ( Alumzinc Panel )

0.50mm (Aluminium Panel

Accessories

Alum 2S – 7S Carrier ( Base on Panel Spacing )

CNL84/4S TYPE LOUVERS

CNL84/4S TYPE LOUVERS

Panel Size

85mm Effective Width

Notes

Panel to Panel Spacing Available

At 74 / 86 / 70 / 100mm

Available in Horiztal& Vertical Type

Thickness

0.35mm ( Alumzinc Panel )

0.50mm (Aluminium Panel

Accessories

Alum 2S – 7S Carrier ( Base on Panel Spacing )

CNL84/5S TYPE LOUVERS

CNL84/5S TYPE LOUVERS

Panel Size

85mm Effective Width

Notes

Panel to Panel Spacing Available

At 74 / 86 / 70 / 100mm

Available in Horiztal& Vertical Type

Thickness

0.35mm ( Alumzinc Panel )

0.50mm (Aluminium Panel

Accessories

Alum 2S – 7S Carrier ( Base on Panel Spacing )

CNL84/6S TYPE LOUVERS

CNL84/6S TYPE LOUVERS

Panel Size

85mm Effective Width

Notes

Panel to Panel Spacing Available

At 74 / 86 / 70 / 100mm

Available in Horiztal& Vertical Type

Thickness

0.35mm ( Alumzinc Panel )

0.50mm (Aluminium Panel

Accessories

Alum 2S – 7S Carrier ( Base on Panel Spacing )

CNL84/7S TYPE LOUVERS

CNL84/7S TYPE LOUVERS

Panel Size

85mm Effective Width

Notes

Panel to Panel Spacing Available

At 74 / 86 / 70 / 100mm

Available in Horiztal& Vertical Type

Thickness

0.35mm ( Alumzinc Panel )

0.50mm (Aluminium Panel

Accessories

Alum 2S – 7S Carrier ( Base on Panel Spacing )

CNL95Z TYPE LOUVERS

CNL95Z TYPE LOUVERS

Panel Size

75/95/140mm Effective Width

Thickness

0.55mm Thick Aluminium Panel

Accessories

Alum Extruded Bracket

CNL140Z TYPE LOUVERS

CNL140Z TYPE LOUVERS

Panel Size

75/95/140mm Effective Width

Thickness

0.55mm Thick Aluminium Panel

Accessories

Alum Extruded Bracket

CNL153S TYPE LOUVERS

CNL153S TYPE LOUVERS

Panel Size

180mm Effective Width

Thickness

0.60mm Aluminium Panel

Accessories

Alum Extruded 153S Bracket

CNL153S TYPE LOUVERS

CNL93S TYPE LOUVERS

Panel Size

93mm Effective Width

Thickness

0.55mm Thick Aluminium Panel

Accessories

Alum Extruded 93S Bracket

CNL 100 X 20 BOX LOUVERS

CNL 100 X 20 BOX LOUVERS

Panel Size

100x20/150x30/200x50 mm

Notes

Custom Made Size Available

Thickness

0.50mm-0.80mm (Aluminium Panel)

Accessories

G.I Baffle Carrier/Alum BL Carrier

CNL150AF AEROFOIL LOUVERS

CNL150AF AEROFOIL LOUVERS

Panel Size

150 / 200 / 330 / 450mm Effective Width

Thickness

0.50 – 0.70mm Thick Aluminium Panel

Accessories

Alum Extruded End Cap

CNL100 / 100G GROOVE LINE CEILING

CNL150AF AEROFOIL LOUVERS

Panel Size

100 / 150 / 200mm Effective Width

Thickness

0.35 – 0.50mm (Alumzinc Panel)

0.50-0.60mm (Aluminium Panel)

Accessories

G.I Carrier / U-Channel / Panel join

CNL100 / 100G GROOVE LINE CEILING "Wood Grain 950

CNL100 / 100G GROOVE LINE CEILING "Wood Grain 950

Panel Size

100 / 150 / 200mm Effective Width

Thickness

0.35 – 0.50mm (Alumzinc Panel)

0.50-0.60mm (Aluminium Panel)

Accessories

G.I Carrier / U-Channel / Panel join

CNL200G GROOVE LINE CEILING

CNL200G GROOVE LINE CEILING

Panel Size

100 / 150 / 200mm Effective Width

Thickness

0.35 – 0.50mm (Alumzinc Panel)

0.50-0.60mm (Aluminium Panel)

Accessories

G.I Carrier / U-Channel / Panel join

CNL100S HAIR LINE CEILING

CNL100S HAIR LINE CEILING

Panel Size

100 / 150 / 200mm Effective Width

Thickness

0.35 – 0.50mm (Alumzinc Panel)

0.50-0.60mm (Aluminium Panel)

Accessories

G.I Carrier / U-Channel / Panel join

CNL150S HAIR LINE CEILING

CNL150S HAIR LINE CEILING

Panel Size

100 / 150 / 200mm Effective Width

Thickness

0.35 – 0.50mm (Alumzinc Panel)

0.50-0.60mm (Aluminium Panel)

Accessories

G.I Carrier / U-Channel / Panel join

CNL 200SQ “SQ” CELL CEILING

CNL 200SQ “SQ” CELL CEILING

Panel Size

75 - 200mm Square cell ceiling

Thickness

0.50mm

Accessories

Connector / Hangging / L-Angle

Colour

Standard Powder Coated White

CNL “SC” screen CEILING

CNL “SC” SCREEN CEILING

Panel Size

100 / 200mm Effective Width

Thickness

0.40 – 0.50mm ( Alumzinc Panel )

0.50 – 0.70mm (Aluminium Panel )

Accessories

G.I SC Carrier

CNL 100 X 20 “ BASSLE CEILING

CNL 100 X 20 “ BASSLE CEILING

Panel Size

100 x 20 / 150 x 30 / 200 x 50 mm

Notes

Custom Made Size Available

Thickness

0.50 – 0.80mm (Aluminium Panel )

Accessories

G.I Baffle Carrier / Alum BL Carrier

CNL 606LO-2 LAY ON TILE CEILING

CNL 606LO-2 LAY ON TILE CEILING

Panel Size

575mm x 575mm x 0.7mm

Notes

CNL 606LO – 1 ( Non Perforated )

CNL 606LO – 2 ( Perforated C/W Black Tissue )

Colour

Standard Powder Coated White

CNL 606CI-1 CLIP IN ON TILE CEILING

CNL 606CI-1 CLIP IN ON TILE CEILING

Panel Size

575mm x 575mm x 0.7mm

Notes

CNL 606CI – 1 ( Non Perforated )

CNL 606CI – 2 ( Perforated C/W Black Tissue )

Colour

Standard Powder Coated White
